土工格栅浅谈塑料土工格栅的安装建议

discussion on the installation of geogrid for geotextile

1.在土工格栅安装在坚固的地面上（cbr > 2），填充材料必须向后倾倒或结束倾倒或腹部倾倒。当将填充材料应用在坚实的地面上时，橡胶轮胎卡车可以直接驱动在速度很慢的土工格栅（小于5英里）和垃圾填充材料作为他们去。经营者必须不转弯或做出任何突然停止时，开车穿过格栅。跟踪设备不能直接驱动在土工格栅。至少有4英寸的填充材料应放置在设备轨道和土工格栅。

1. the geogrid is mounted on a solid ground (cbr > 2), and the filling material must be dumped or toppled or toppled. when filling materials are applied to a solid ground, rubber tire trucks can be directly driven at slow speed geogrids (less than 5 miles) and garbage filled materials as they go. the operator must drive through the grille without turning or making any sudden stop. the tracking device can not be directly driven in the geogrid. at least 4 inches of filling material should be placed on the equipment track and geotextile grille.

2.在软土地基中应用的填充材料（cbr在1-2之间）和地面很软（cbr＜1），没有任何设备可以直接开车穿过格栅。指定的填充材料应放置和使用具有一个每平方英寸不到4磅的地面压力。指定的填充材料的位置应从土工格栅边缘的地方。填上土工格栅安置前推广应骑在指定填充层的总完成厚度上的卡车。用于传播的设备土工格栅应小心抬刀作为设备向前移动以卷填到网格。一至少4英寸的填充土工格栅及操作设备间所需的轨道使用传播紧转弯，禁止突然停止或旋转的轨道。

2. the filling materials used in the soft soil foundation (cbr between 1-2) and the ground are very soft (cbr < 1), and no equipment can drive through the grille directly. the specified filling material should be placed and used with a ground pressure of less than 4 pounds per square inch. the position of the specified filling material should be from the edge of the geogrid. the truck that should be promoted on the total completed thickness of the specified filling layer before filling the geogrid. the geogrid used for transmission of equipment should be careful to move forward as a device to fill the grid. a at least 4 inches of filled geogrid and operating equipment need to be used to transmit a tight curve to prevent a sudden stop or rotating orbit.

3.任何传播或压实在车辙发展必须充满额外的填充材料来达到设计厚度。

3. any transmission or compaction in the rut development must be filled with additional filling materials to reach the design thickness.

4.基层材料应按设计要求放置在电梯的厚度和压实。

4. the base material should be placed in the thickness and compaction of the elevator according to the design requirements.

5.塑料土工格栅部分损坏，在安装过程中必须切断并去除。更换部分应以3英尺的两侧，并用塑料领带固定。

5. the plastic geogrid partially damaged, must be cut off and removed during the installation process. the replacement part should be on both sides of 3 feet and fixed with a plastic tie.

6.k8凯发-凯发app认为塑料土工格栅应能防止在运输和储存过程中的长期暴露阳光直射。

6. guiyang geogrid considers that the plastic geogrid should be able to prevent exposure to direct sunlight in the course of transportation and storage.

7.塑料土工格栅放置后，三周不得离开。

7. plastic geogrid can not be left after three weeks.

8.工程师应核实路基塑料土工格栅是准备部署，这也表明在合同图纸。

8. engineers should verify that the roadbed plastic geogrid is ready to deploy, which also shows in the contract drawings.

9.表面应平整无树桩、尖锐物体和碎片，这些可能会损坏塑料土工格栅。

9. the surface should be smooth without stump, sharp object and debris, which may damage the plastic geogrid.

10.将土工格栅在路基和施加张力用手消除皱纹。

10. remove the wrinkles by using the geogrid in the subgrade and the exertion of tension.

11.土工格栅板重叠的要求，要么并排，或端到端，应依靠的力量路基。对于软土路基（cbr＜1），推荐3英尺的重叠；软土路基（cbr =1-2），推荐2英尺，和坚定的路基（cbr＞2）1脚。

11. geogrid overlapped requirements, either side by side, or end to end, should rely on the strength of the subgrade. for soft soil subgrade (cbr < 1), it is recommended that 3 feet overlap; soft soil subgrade (cbr =1-2), recommended 2 feet, and a firm subgrade (cbr > 2) 1 feet.

12.相邻的土工格栅卷应在预期填补传播方向重叠。

12. adjacent geogrid rolls should overlap in the expected filling direction.

13.塑料领带应在10英尺的间隔时间，以确保重叠。

13. plastic neckties should be at intervals of 10 feet to ensure overlap.
