土工格栅的意义是什么？

what is the significance of the geogrid?

1.塑料土工格栅

1. plastic geogrid

塑料土工格栅是经过拉伸形成的具有方形或矩形的聚合物网材，按其制造时拉伸方向的不同可为单向拉伸和双向拉伸两种。它是在经挤压制出的聚合物板材（原料多为聚丙烯或高密度聚乙烯）上冲孔，然后在加热条件下施行定向拉伸。单向拉伸格栅只沿板材长度方向拉伸制成，而双向拉伸格栅则是继续将单向拉伸的格栅再在与其长度垂直的方向拉伸制成。

the plastic geogrid is a polymer mesh with square or rectangular shape formed by stretching. according to its manufacturing direction, the tensile direction can be two kinds: uniaxial tension and biaxial stretching. it is a extruded polymer sheet (the raw material is mostly polypropylene or high density polyethylene) punching, and then subjected to directional stretching under heating conditions. the unidirectional tensile grid is only stretched along the length direction of the sheet, while the biaxially stretched grid continues to stretch the unidirectional stretched grille in the direction perpendicular to its length.

由于塑料土工格栅在制造中聚合物的高分子会随加热延伸过程而重新排列定向，加强了分子链间的联结力，达到了提高其强度的目的。其延伸率只有原板材的10%～15%。如果在土工格栅中加入炭黑等抗老化材料，可使其具有较好的耐酸、耐碱、耐腐蚀和抗老化等耐久性能。

due to the rearrangement of polymers in the manufacture of plastic geogrids, polymers will rearrange their orientation along with the heating and extending process, and enhance the bonding force between molecular chains, so as to improve their strength. its elongation is only 10% ~ 15% of the original plate. if the anti aging material such as carbon black is added to the geogrid, it can have good durability, such as acid resistance, alkali resistance, corrosion resistance and aging resistance.

k8凯发-凯发app认为塑料土工格栅在施工时应注意下列问题：支撑在预制混凝土基础上，其宽度不大于30cm，厚度不小于20cm，埋深不小于60cm防止地基冻胀影响；筋材铺设，筋材主强度方向应垂直于墙面，以销钉固定；平整墙基，按设计要求开挖、平整；软土需压实或换填，压实到要求密度，应略超出墙面范围。

plastic geogrid should pay attention to the following questions: in the construction of precast concrete support on the basis, the width is not more than 30cm, the thickness of not less than 20cm, depth of not less than 60cm to prevent the frost heaving of foundation reinforcement effect; laying reinforcement strength, the main direction should be perpendicular to the wall, with the pin fixed flat wall, according to the design requirements; excavation, smooth; soft soil to compaction or replacement, compaction requirements should be slightly beyond the scope of the wall density.

1.1单向土工格栅

1.1 unidirectional geogrid

单向土工格栅是由高分子聚合物经挤出压成薄板再冲规则孔网，然后纵向拉伸而成.这种过程中使高分子成定向线性状态并形成分布均匀、节点强度高的长椭圆形网状整体性结构此种结构具有相当高的拉伸强度和拉伸模量。

uniaxial geogrid is a polymer pressure into a sheet by extrusion and punching network rules, and then the longitudinal stretch. this process make the linear polymer into a state of orientation and form uniform distribution of nodes of high strength long oval mesh structure integrity of the structure has the high tensile strength and tensile modulus.

单向土工格栅的主要用途是加固软弱地基；加筋沥青或水泥路面；加固路堤坝迦坡及挡土墙；加固江河海堤；处理垃圾掩埋场。单向土工格栅的特殊用途：抗低温性。

the main purpose of the one-way geogrid is to consolidate the soft foundation; reinforce the asphalt or cement road; reinforce the embankment, the slope and the retaining wall; reinforce the river embankment; and deal with the landfill. special use of unidirectional geogrid: low temperature resistance.

1.2双向土工格栅

1.2 bi-directional geogrid

双向土工格栅是用高分子聚合物通过挤压、成板、冲孔过程后再纵向、横向拉伸而成。该材料在纵向和横向上都具有很大的拉伸强度，这种结构在土壤中同样也能提供一个更为有效的力的承担和扩散的理想的连锁系统，适应于大面积永久性承载的地基。

bi-directional geogrid is made of high molecular polymer through extrusion, plate forming and punching, and then lengthwise and laterally. the material has great tensile strength both vertically and horizontally. this structure can also provide a more effective ideal chain system for bearing and diffusing, which is suitable for large-area permanent bearing foundation.

双向拉伸塑料土工格栅适用于各种堤坝和路基补强、边坡防护、洞壁补强，大型机场、停车场、码头货场等永久性承载的地基补强。

biaxially oriented plastic geogrid is suitable for various kinds of dams and subgrade reinforcement, slope protection, wall reinforcement, large airport, parking lot, freight yard and permanent foundation reinforcement.

双向土工格栅的主要作用有增大路（地）基的承载力，延长路（地）基的使用寿命；防止路（地）面塌陷或产生裂纹，保持地面美观整齐；施工方便，省时，省力，缩短工期，减少维修费用；防止涵洞产生裂纹；增强土坡，防止水土流失；减少垫层厚度，节约造价；支撑边坡植草网垫的稳定性绿化环境；可取代金属网，用于煤矿井下假顶网。

the main function of bidirectional geogrid increases the road (ground) bearing base, yan changlu (the) based service life; prevent the road (ground) surface subsidence or cracking, keep the floor clean and beautiful; the construction is convenient, time-saving, labor-saving, shorten the construction period, reduce maintenance costs; to prevent the cracks in culvert reinforcement; the soil, prevent soil erosion; reduce cushion thickness, and save cost; support the stability of the slope of grass mat greening; can replace the metal mesh, used for coal mine top net.

2.钢塑土工格栅

2. steel plastic geogrid

钢塑土工格栅以高强钢丝（或其他纤维），经特殊处理，与聚乙烯（pe），并添加其他助剂，通过挤出使之成为复合型高强抗拉条带，且表面有粗糙压纹，则为高强加筋土工带。由此单带，经纵、横按一定间距编制或夹合排列，采用特殊强化粘接的熔焊技术焊接其交接点而成型，则为加筋土工格栅。

the steel plastic geogrid is made of high strength steel wire or other fibers. after special treatment, it is extruded into polyethylene composite (pe) and other auxiliaries to make it into a composite high-strength tensile strip, and the surface has rough embossing, which is a high strength reinforced geotextile. therefore, the single belt should be vertically or horizontally spaced or arranged in a certain distance, and then the special reinforcement bonding technology is applied to weld the junction point and form the reinforced geogrid.

该产品的主要特点有强度大、变形小；蠕变小；耐腐蚀、寿命长；施工方便快捷、周期短、成本低等。主要应用于公路、铁路、桥台、引道、码头、水坝、渣场等的软土地基加固、挡墙和路面抗裂工程等领域。

the main features of the product are large strength, small deformation, small creep, corrosion resistance, long life, convenient and quick construction, short cycle and low cost. it is mainly used in highway, railway, abutment, diversion, wharf, dam, slag field and other soft soil foundation reinforcement, retaining wall and pavement anti cracking engineering and other fields.

钢塑土工格栅的主要工程特征有强度大、蠕变小、适应各类环境土壤，完全可以满足高等级公路中的高大挡墙使用；能有效的提高加筋承载面的嵌锁、咬合作用、极大程度的增强地基的承载力、有效的约束土体的侧向位移，增强地基稳固性能；与传统格栅相比更具有强度大、承载力强、抗腐蚀、防老化、摩擦系数大、孔眼均匀、施工方便、使用寿命长等特点；更适应于深海作业、堤岸加固，从根本上解决了其他材料做石笼因长期受海水冲蚀而造成的强度低、耐腐蚀性能差、使用寿命短等技术难题；能有效的避免在施工过程中被机具碾压、破坏而造成的施工损伤。

the main engineering plastic geogrid has the characteristics of high strength, low creep, adapt to all kinds of soil environment, can fully meet the use of tall retaining wall in highway; can effectively improve the reinforced bearing surface, occlusal function, interlocking greatly improve foundation bearing capacity, effectively restrain the soil lateral displacement of reinforced foundation stable performance; compared with the traditional grid with high strength, strong bearing capacity, corrosion resistance, anti aging, friction coefficient, hole characteristics uniform, convenient construction, long service life; more suitable for deep-sea operations, embankment reinforcement, and fundamentally solve the other materials due to the long stone cage caused by seawater erosion the low strength, poor corrosion resistance, short service life can effectively avoid technical problems; in the construction process of rolling machine, is caused by the failure of construction damage.

3.玻璃纤维土工格栅

3. glass fiber geogrid

玻璃纤维土工格栅是以玻璃纤维为材质，采用一定的编织工艺制成的网状结构材料，为保护玻璃纤维、提高整体使用性能，经过特殊的涂复处理工艺而成的土工复合材料。它是一种用于路面增强、老路补强，加固路基及软土基的优良土工合成材料。在处理沥青路面反射裂纹应用上，已成为不可替代的材料。该产品是以高强无碱玻璃纤维通过国际先进的经编工艺制成网状基材，经表面涂覆处理而制成的半刚性制品。

fiberglass geogrid is a netted material made of glass fiber and woven technology. it is a geotextile made by special coating process to protect fiberglass and improve its overall performance. it is a good geosynthetic material for pavement reinforcement, old road reinforcement, reinforcement of subgrade and soft soil foundation. it has become an irreplaceable material to deal with the application of reflective cracks in asphalt pavement. this product is made of high strength alkali free glass fiber through the international advanced warp knitting technology to make a reticulate base material, the semi-rigid products made of surface coating treatment.

玻璃纤维土工格栅的主要特点有高抗拉强度、低延伸率；无长期蠕变；热稳定性；与沥青混合的相容性；物理化学稳定性；集料嵌锁

the main characteristics of glass fiber geogrid has high tensile strength and low elongation; no long-term creep; thermal stability; compatibility with asphalt mixture; physical and chemical stability of aggregate interlock;
